Details

 1) Design speed:120m/min; Effective width:1400-2500mm

2) Precision of cutting cardboard:+-1mm

3) Length of cutting cardboard:500-9999mm.

4) Computer system to keep order.man-machine conversation system NC. Automatic adjust cutting speed by cardboard specification and maching.The screen display various production message .Can consult,modification,superaddition and cancel order during running machine.

5)High quality servo motor,the servo drive system import from Germany.

6)Transmission system adopts oil pump auto-Cye lubricate.

7)Exact and adjustable no gap gear assure knife-edge joggle exactly. incision quality good, beeline degree high, protect knives.

8)Single face conveyor machine:

Max,stacking height 2000mm,

Max stacking length 1800mm.

Design speed:100m/min.

9)Conveyor system after the slitter and cutter is applied to delivery the board on two direction,for rise efficiency and easy stacking.

10) It will be more suitable for large or moderate manufactories of offset printing box.

11) Can save more than 200 groups order, can change cutting size exactly in short time without stop, can connect to computer system, this makes the production management good.

12) Roll for leading paperboard has anti-skid material cover, more wear-resisting, size is correct.

13) Servo control motor drive, 5.7 inch Colorful touch screen, you can check every item clearly.
